Omega Products BT40 Synchro Tapping Chuck - ER16 - Capacity M3 - M12

Omega Products BT40 Synchro Tapping Chucks


From
£152.77
View Products
Need Help?
Contact Sales

BT40 Synchro Tapping Chucks are designed to provide efficient and precise tapping operations in BT40 spindle machines. With their high-speed capabilities and robust construction, these chucks are suitable for a wide range of tapping applications. The synchro tapping mechanism ensures synchronous rotation between the chuck and the spindle, eliminating the need for rigid tapping or tapping cycles. This results in improved thread quality, reduced cycle times, and enhanced tool life.


Product SKU Taper Collet Size Capacity Clamping Range Gauge Length Form D1 D2 Comp. Exp. Price Stock
OM32384 BT40 ER16 M3-M12 1-10 79 AD/B 32 34 0.5 0.5 £152.77 4
OM32385 BT40 ER20 M3-M16 3.5-10 85 AD/B 35 34 0.5 0.5 £164.34 6
OM32386 BT40 ER25 M3-M20 3.5-16 89 AD/B 42 34 0.5 0.5 £164.34 6
OM32418 BT40 ER32 M4-M27 3.5-20 110 AD/B 50 45 0.5 0.5 £168.97 3
OM32433 BT40 ER40 M6-M33 6-26 115 AD/B 63 62 0.5 0.5 £177.07 0
