Omega Products BT50 Synchro Tapping Chuck - ER16 - Capacity M3 - M12

Omega Products BT50 Synchro Tapping Chucks


From
£187.48
View Products
Need Help?
Contact Sales

BT50 Synchro Tapping Chucks are designed to provide efficient and precise tapping operations in BT50 spindle machines. With their high-speed capabilities and robust construction, these chucks are suitable for a wide range of tapping applications. The synchro tapping mechanism ensures synchronous rotation between the chuck and the spindle, eliminating the need for rigid tapping or tapping cycles. This results in improved thread quality, reduced cycle times, and enhanced tool life.


Product SKU Taper Collet Size Capacity Clamping Range Gauge Length Form D1 D2 Comp. Exp. Price Stock
OM32434 BT50 ER16 M3-M12 1-10 95 AD/B 32 34 0.5 0.5 £187.48 0
OM32435 BT50 ER20 M3-M16 3.5-10 100 AD/B 35 34 0.5 0.5 £201.38 0
OM32436 BT50 ER25 M3-M20 3.5-16 110 AD/B 42 34 0.5 0.5 £201.38 1
OM32437 BT50 ER32 M4-M27 3.5-20 120 AD/B 50 45 0.5 0.5 £210.64 8
OM32438 BT50 ER40 M6-M33 6-26 120 AD/B 63 62 0.5 0.5 £218.73 3
