Widin Carbide Corner Radius End Mill For Mold & Die - 2 Flute Tapered Neck Type -0.2mm x 1mm x R0.05 x 1

Widin Carbide Corner Radius End Mill For Mold & Die - 2 Flute Tapered Neck Type (WR542)


From
£32.11
View Products
Need Help?
Contact Sales

The Widin Carbide Corner Radius End Mill for Mold & Die is specifically designed to meet the demands of precision machining applications. With its 2-flute configuration and tapered neck type, this end mill offers reduced high strength and chattering, resulting in smoother and more precise cutting operations. The tapered effective length enhances stability and rigidity, allowing for improved performance in deep groove machining. Additionally, this end mill comes in various specifications, providing flexibility for different machining needs and effectively addressing the requirements of deep groove applications.


Product SKU Cutter Diameter Number of Flutes Flute Length Overall Length Shank Diameter Reach Corner Radius Taper Angle Price Stock
UR5420020050101 0.2 2 0.3 40 4 1 0.05 £43.24 0
UR5420020050201 0.2 2 0.3 40 4 1 0.05 £43.24 0
UR5420020050103 0.2 2 0.3 40 4 3 0.05 £43.24 0
UR5420020050203 0.2 2 0.3 40 4 3 0.05 £43.24 0
UR5420020050102 0.2 2 0.3 40 4 2 0.05 £43.24 0
UR5420020050202 0.2 2 0.3 40 4 2 0.05 £43.24 0
UR5420030050102 0.3 2 0.5 40 4 2 0.05 £37.80 0
UR5420030050103 0.3 2 0.5 40 4 3 0.05 £37.80 0
UR5420030050104 0.3 2 0.5 40 4 4 0.05 £42.54 0
UR5420030050202 0.3 2 0.5 40 4 2 0.05 £37.80 0
UR5420030050105 0.3 2 0.5 40 4 5 0.05 £42.54 0
UR5420040050102 0.4 2 0.6 50 4 2 0.05 £39.30 0
UR5420040050103 0.4 2 0.6 50 4 3 0.05 £39.30 0
UR5420030050203 0.3 2 0.5 40 4 3 0.05 £37.80 0
UR5420030050205 0.3 2 0.5 40 4 5 0.05 £42.54 0
UR5420030050204 0.3 2 0.5 40 4 4 0.05 £42.54 0
UR5420040050104 0.4 2 0.6 50 4 4 0.05 £39.30 9
UR5420040050105 0.4 2 0.6 50 4 5 0.05 £39.30 0
UR5420040050202 0.4 2 0.6 50 4 2 0.05 £39.30 0
UR5420040050106 0.4 2 0.6 50 4 6 0.05 £39.30 0
UR5420040050203 0.4 2 0.6 50 4 3 0.05 £39.30 0
UR5420040050204 0.4 2 0.6 50 4 4 0.05 £39.30 0
UR5420040050206 0.4 2 0.6 50 4 6 0.05 £39.30 0
UR542004010102 0.4 2 0.6 50 4 2 0.1 £39.30 0
UR5420040050205 0.4 2 0.6 50 4 5 0.05 £39.30 0
UR542004010103 0.4 2 0.6 50 4 3 0.1 £39.30 0
UR542004010104 0.4 2 0.6 50 4 4 0.1 £39.30 0
UR542004010106 0.4 2 0.6 50 4 6 0.1 £39.30 7
UR542004010202 0.4 2 0.6 50 4 2 0.1 £39.30 0
UR542004010105 0.4 2 0.6 50 4 5 0.1 £39.30 0
UR542004010204 0.4 2 0.6 50 4 4 0.1 £39.30 0
UR5420050050104 0.5 2 0.7 50 4 4 0.05 £32.11 0
UR542004010203 0.4 2 0.6 50 4 3 0.1 £39.30 0
UR542004010205 0.4 2 0.6 50 4 5 0.1 £39.30 0
UR542004010206 0.4 2 0.6 50 4 6 0.1 £39.30 0
UR5420050050206 0.5 2 0.7 50 4 6 0.05 £32.11 0
UR5420050050108 0.5 2 0.7 50 4 8 0.05 £32.11 0
UR5420050050106 0.5 2 0.7 50 4 6 0.05 £32.11 0
UR5420050050204 0.5 2 0.7 50 4 4 0.05 £32.11 0
UR5420050050110 0.5 2 0.7 50 4 10 0.05 £32.11 0
UR5420050050208 0.5 2 0.7 50 4 8 0.05 £32.11 0
UR542005010106 0.5 2 0.7 50 4 6 0.1 £32.11 0
UR542005010110 0.5 2 0.7 50 4 10 0.1 £32.11 0
UR5420050050210 0.5 2 0.7 50 4 10 0.05 £32.11 0
UR542005010104 0.5 2 0.7 50 4 4 0.1 £32.11 0
UR542005010108 0.5 2 0.7 50 4 8 0.1 £32.11 0
UR542005010206 0.5 2 0.7 50 4 6 0.1 £32.11 0
UR542005010208 0.5 2 0.7 50 4 8 0.1 £32.11 0
UR542006010204 0.6 2 0.9 50 4 4 0.1 £32.11 0
UR542005010204 0.5 2 0.7 50 4 4 0.1 £32.11 0
UR542006010112 0.6 2 0.9 50 4 12 0.1 £32.11 0
UR542006010110 0.6 2 0.9 50 4 10 0.1 £32.11 0
UR542006010108 0.6 2 0.9 50 4 8 0.1 £32.11 3
UR542005010210 0.5 2 0.7 50 4 10 0.1 £32.11 0
UR542006010104 0.6 2 0.9 50 4 4 0.1 £32.11 0
UR542006010206 0.6 2 0.9 50 4 6 0.1 £32.11 0
UR542006010208 0.6 2 0.9 50 4 8 0.1 £32.11 0
UR542006010106 0.6 2 0.9 50 4 6 0.1 £32.11 0
UR542006020104 0.6 2 0.9 50 4 4 0.2 £32.11 0
UR542006020106 0.6 2 0.9 50 4 6 0.2 £32.11 0
UR542006010212 0.6 2 0.9 50 4 12 0.1 £32.11 0
UR542006010210 0.6 2 0.9 50 4 10 0.1 £32.11 0
UR542006020110 0.6 2 0.9 50 4 10 0.2 £32.11 0
UR542006020108 0.6 2 0.9 50 4 8 0.2 £32.11 0
UR542006020208 0.6 2 0.9 50 4 8 0.2 £32.11 0
UR542006020112 0.6 2 0.9 50 4 12 0.2 £32.11 0
UR542006020204 0.6 2 0.9 50 4 4 0.2 £32.11 0
UR542006020206 0.6 2 0.9 50 4 6 0.2 £32.11 0
UR542008010112 0.8 2 1.2 50 4 12 0.1 £32.11 2
UR542008010208 0.8 2 1.2 50 4 8 0.1 £32.11 0
UR542006020212 0.6 2 0.9 50 4 12 0.2 £32.11 0
UR542008010108 0.8 2 1.2 50 4 8 0.1 £32.11 0
UR542006020210 0.6 2 0.9 50 4 10 0.2 £32.11 0
UR542008010106 0.8 2 1.2 50 4 6 0.1 £32.11 0
UR542008010110 0.8 2 1.2 50 4 10 0.1 £32.11 0
UR542008010116 0.8 2 1.2 50 4 16 0.1 £36.98 0
UR542008010104 0.8 2 1.2 50 4 4 0.1 £32.11 0
UR542008010206 0.8 2 1.2 50 4 6 0.1 £32.11 0
UR542008010204 0.8 2 1.2 50 4 4 0.1 £32.11 0
UR542008020112 0.8 2 1.2 50 4 12 0.2 £32.11 0
UR542008010210 0.8 2 1.2 50 4 10 0.1 £32.11 0
UR542008020106 0.8 2 1.2 50 4 6 0.2 £32.11 0
UR542008020104 0.8 2 1.2 50 4 4 0.2 £32.11 0
UR542008010212 0.8 2 1.2 50 4 12 0.1 £32.11 0
UR542008020108 0.8 2 1.2 50 4 8 0.2 £32.11 0
UR542008010216 0.8 2 1.2 50 4 16 0.1 £36.98 0
UR542008020206 0.8 2 1.2 50 4 6 0.2 £32.11 0
UR542008020204 0.8 2 1.2 50 4 4 0.2 £32.11 0
UR542008020110 0.8 2 1.2 50 4 10 0.2 £32.11 0
UR542008020208 0.8 2 1.2 50 4 8 0.2 £32.11 0
UR542008020210 0.8 2 1.2 50 4 10 0.2 £32.11 0
UR542008020212 0.8 2 1.2 50 4 12 0.2 £32.11 0
UR542008020216 0.8 2 1.2 50 4 16 0.2 £36.98 0
UR542008020116 0.8 2 1.2 50 4 16 0.2 £36.98 0
UR542010010106 1 2 1.5 50 4 6 0.1 £27.59 0
UR542010010110 1 2 1.5 50 4 10 0.1 £27.59 0
UR542010010108 1 2 1.5 50 4 8 0.1 £27.59 0
UR542010010116 1 2 1.5 50 4 16 0.1 £27.59 0
UR542010010120 1 2 1.5 50 4 20 0.1 £27.59 0
UR542010010130 1 2 1.5 70 4 30 0.1 £35.72 0
UR542010010125 1 2 1.5 60 4 25 0.1 £33.50 0
UR542010010206 1 2 1.5 50 4 6 0.1 £27.59 0
UR542010010150 1 2 1.5 90 6 50 0.1 £41.98 0
UR542010010140 1 2 1.5 80 4 40 0.1 £39.07 0
UR542010010112 1 2 1.5 50 4 12 0.1 £27.59 0
UR542010010210 1 2 1.5 50 4 10 0.1 £27.59 0
UR542010010230 1 2 1.5 70 4 30 0.1 £35.72 0
UR542010010208 1 2 1.5 50 4 8 0.1 £27.59 0
UR542010010212 1 2 1.5 50 4 12 0.1 £27.59 0
UR542010010216 1 2 1.5 50 4 16 0.1 £27.59 0
UR542010010220 1 2 1.5 50 4 20 0.1 £27.59 0
UR542010020130 1 2 1.5 70 4 30 0.2 £35.72 0
UR542010010225 1 2 1.5 60 4 25 0.1 £33.50 0
UR542010020120 1 2 1.5 50 4 20 0.2 £27.59 0
UR542010010240 1 2 1.5 80 4 40 0.1 £39.07 0
UR542010020106 1 2 1.5 50 4 6 0.2 £27.59 0
UR542010010250 1 2 1.5 90 6 50 0.1 £46.37 0
UR542010020112 1 2 1.5 50 4 12 0.2 £27.59 0
UR542010020108 1 2 1.5 50 4 8 0.2 £27.59 0
UR542010020206 1 2 1.5 50 4 6 0.2 £27.59 0
UR542010020208 1 2 1.5 50 4 8 0.2 £27.59 0
UR542010020110 1 2 1.5 50 4 10 0.2 £27.59 0
UR542010020116 1 2 1.5 50 4 16 0.2 £27.59 0
UR542010020125 1 2 1.5 60 4 25 0.2 £33.50 0
UR542010020150 1 2 1.5 90 6 50 0.2 £41.98 0
UR542010020212 1 2 1.5 50 4 12 0.2 £27.59 0
UR542010020140 1 2 1.5 80 4 40 0.2 £39.07 0
UR542010020216 1 2 1.5 50 4 16 0.2 £27.59 0
UR542010020210 1 2 1.5 50 4 10 0.2 £27.59 0
UR542010020225 1 2 1.5 60 4 25 0.2 £33.50 0
UR542010020220 1 2 1.5 50 4 20 0.2 £27.59 0
UR542010020250 1 2 1.5 90 6 50 0.2 £46.37 0
UR542012010108 1.2 2 1.8 50 4 8 0.1 £27.59 0
UR542010020240 1 2 1.5 80 4 40 0.2 £39.07 0
UR542012010112 1.2 2 1.8 50 4 12 0.1 £27.59 0
UR542012010208 1.2 2 1.8 50 4 8 0.1 £27.59 0
UR542012010120 1.2 2 1.8 50 4 20 0.1 £27.59 0
UR542010020230 1 2 1.5 70 4 30 0.2 £35.72 0
UR542012010125 1.2 2 1.8 60 4 25 0.1 £33.50 0
UR542012020108 1.2 2 1.8 50 4 8 0.2 £27.59 0
UR542012010130 1.2 2 1.8 70 4 30 0.1 £35.72 0
UR542012010212 1.2 2 1.8 50 4 12 0.1 £27.59 0
UR542012010116 1.2 2 1.8 50 4 16 0.1 £27.59 0
UR542012010220 1.2 2 1.8 50 4 20 0.1 £27.59 0
UR542012020116 1.2 2 1.8 50 4 16 0.2 £27.59 0
UR542012020212 1.2 2 1.8 50 4 12 0.2 £27.59 0
UR542012020216 1.2 2 1.8 50 4 16 0.2 £27.59 0
UR542012010230 1.2 2 1.8 70 4 30 0.1 £35.72 0
UR542012020112 1.2 2 1.8 50 4 12 0.2 £27.59 0
UR542012010216 1.2 2 1.8 50 4 16 0.1 £27.59 0
UR542012010225 1.2 2 1.8 60 4 25 0.1 £33.50 0
UR542012020125 1.2 2 1.8 60 4 25 0.2 £33.50 0
UR542012020120 1.2 2 1.8 50 4 20 0.2 £27.59 0
UR542012020130 1.2 2 1.8 70 4 30 0.2 £35.72 0
UR542012020208 1.2 2 1.8 50 4 8 0.2 £27.59 0
UR542015010116 1.5 2 2.3 50 4 16 0.1 £27.59 0
UR542015010112 1.5 2 2.3 50 4 12 0.1 £27.59 0
UR542012020230 1.2 2 1.8 70 4 30 0.2 £35.72 0
UR542015010108 1.5 2 2.3 50 4 8 0.1 £27.59 0
UR542015010208 1.5 2 2.3 50 4 8 0.1 £27.59 0
UR542015010125 1.5 2 2.3 60 4 25 0.1 £28.63 0
UR542015010140 1.5 2 2.3 80 4 40 0.1 £36.63 0
UR542012020225 1.2 2 1.8 60 4 25 0.2 £33.50 0
UR542012020220 1.2 2 1.8 50 4 20 0.2 £27.59 0
UR542015010210 1.5 2 2.3 50 4 10 0.1 £27.59 0
UR542015010110 1.5 2 2.3 50 4 10 0.1 £27.59 0
UR542015010212 1.5 2 2.3 50 4 12 0.1 £27.59 0
UR542015010130 1.5 2 2.3 70 4 30 0.1 £32.11 0
UR542015010150 1.5 2 2.3 90 4 50 0.1 £39.65 0
UR542015010120 1.5 2 2.3 50 4 20 0.1 £27.59 0
UR542015010216 1.5 2 2.3 50 4 16 0.1 £27.59 0
UR542015010220 1.5 2 2.3 50 4 20 0.1 £27.59 0
UR542015010225 1.5 2 2.3 60 4 25 0.1 £28.63 0
UR542015010240 1.5 2 2.3 80 6 40 0.1 £42.78 0
UR542015010250 1.5 2 2.3 90 6 50 0.1 £46.37 0
UR542015020110 1.5 2 2.3 50 4 10 0.2 £27.59 0
UR542015020108 1.5 2 2.3 50 4 8 0.2 £27.59 0
UR542015020150 1.5 2 2.3 90 4 50 0.2 £39.65 0
UR542015020130 1.5 2 2.3 70 4 30 0.2 £32.11 0
UR542015020140 1.5 2 2.3 80 4 40 0.2 £36.63 0
UR542015020112 1.5 2 2.3 50 4 12 0.2 £27.59 0
UR542015020210 1.5 2 2.3 50 4 10 0.2 £27.59 0
UR542015020116 1.5 2 2.3 50 4 16 0.2 £27.59 0
UR542015020120 1.5 2 2.3 50 4 20 0.2 £27.59 0
UR542015020212 1.5 2 2.3 50 4 12 0.2 £27.59 0
UR542015010230 1.5 2 2.3 70 4 30 0.1 £32.11 0
UR542015020225 1.5 2 2.3 60 4 25 0.2 £28.63 0
UR542015020208 1.5 2 2.3 50 4 8 0.2 £27.59 0
UR542015020220 1.5 2 2.3 50 4 20 0.2 £27.59 0
UR542015020125 1.5 2 2.3 60 4 25 0.2 £28.63 0
UR542015020230 1.5 2 2.3 70 4 30 0.2 £32.11 0
UR542015020216 1.5 2 2.3 50 4 16 0.2 £27.59 0
UR542015020240 1.5 2 2.3 80 6 40 0.2 £42.78 0
UR542015020250 1.5 2 2.3 90 6 50 0.2 £46.37 0
UR542015030108 1.5 2 2.3 50 4 8 0.3 £27.59 0
UR542015030112 1.5 2 2.3 50 4 12 0.3 £27.59 0
UR542015030120 1.5 2 2.3 50 4 20 0.3 £27.59 0
UR542015030140 1.5 2 2.3 80 4 40 0.3 £36.63 0
UR542015030110 1.5 2 2.3 50 4 10 0.3 £27.59 0
UR542015030116 1.5 2 2.3 50 4 16 0.3 £27.59 0
UR542015030130 1.5 2 2.3 70 4 30 0.3 £32.11 0
UR542015030208 1.5 2 2.3 50 4 8 0.3 £27.59 0
