Widin Carbide End Mill For Mold & Die - 2 Flute Straight Ball - 5mm

Widin Carbide End Mill For Mold & Die - 2 Flute Straight Ball (WSB502)


From
£27.59
View Products
Need Help?
Contact Sales

The 2-flute Straight Ball design (WSB502) incorporates several features that enhance its performance and versatility. The cutting edge of this end mill is crafted with a high-precision R tolerance, ensuring exceptional accuracy and delivering high-quality machining results. This feature enables the creation of intricate and precise shapes with superior surface finishes. Additionally, the straight flute shape of the end mill enhances the hardness of the flute, increasing its durability and resistance to wear. This results in extended tool life and improved performance even when working with tough materials.


Product SKU Cutter Diameter Number of Flutes Flute Length Overall Length Shank Diameter Radius Price Stock
USB502050 5 2 18 90 6 2.5 £29.91 2
USB502060 6 2 20 90 6 3 £29.91 0
USB502040 4 2 12 70 6 2 £27.59 0
USB502030 3 2 10 70 6 1.5 £27.59 1
USB502080 8 2 25 100 8 4 £48.11 0
USB502120 12 2 32 110 12 6 £85.22 1
USB502160 16 2 35 150 16 8 £195.93 0
USB502200 20 2 40 150 20 10 £251.72 0
USB502100 10 2 30 100 10 5 £62.02 0
