Widin Carbide End Mill For Mold & Die - 4 Flute Ball Nose (WB504)
From
£25.63
View Products
£25.63
With its 4-flute design, it offers increased cutting efficiency and versatility. The end mill features a high-strength cutting edge that is achieved through the application of an optimized rake angle. This ensures exceptional cutting performance, durability, and longevity, even under demanding machining conditions. Additionally, the WB504 model incorporates a centre match type 3, which enables excellent workpiece finishes, particularly during high-speed processing. This feature ensures smooth and precise machining operations, resulting in superior surface finishes on the machined components.
| Product SKU | Cutter Diameter | Number of Flutes | Flute Length | Overall Length | Shank Diameter | Radius | Price | Stock | |
|---|---|---|---|---|---|---|---|---|---|
| UB504010 | 1 | 4 | 1 | 50 | 6 | 0.5 | £25.63 | 0 | View product |
| UB504015 | 1.5 | 4 | 1.5 | 50 | 6 | 0.75 | £25.63 | 1 | View product |
| UB504020 | 2 | 4 | 2 | 50 | 6 | 1 | £25.63 | 0 | View product |
| UB504030 | 3 | 4 | 3 | 60 | 6 | 1.5 | £27.59 | 0 | View product |
| UB504040 | 4 | 4 | 4 | 70 | 6 | 2 | £27.59 | 0 | View product |
| UB504050 | 5 | 4 | 5 | 80 | 6 | 2.5 | £29.91 | 0 | View product |
| UB504060 | 6 | 4 | 6 | 90 | 6 | 3 | £29.91 | 1 | View product |
| UB504100 | 10 | 4 | 10 | 100 | 10 | 5 | £62.02 | 0 | View product |
| UB504080 | 8 | 4 | 8 | 100 | 8 | 4 | £48.11 | 2 | View product |
| UB504120 | 12 | 4 | 12 | 110 | 12 | 6 | £85.22 | 0 | View product |
