Asimeto Digital Outside Micrometers - IP65 - 105 Series - 25-50mm (Metric/Imperial Conversion)

Designed for production floors, workshops, and field service teams, the Asimeto Digital Outside Micrometer IP65 105 Series delivers precise 25–50 mm external measurements with rugged, dependable performance in challenging environments.

• Measurement range: 25–50 mm external measurement with built‑in inch/metric conversion for quick cross‑unit reads.
• Resolution: 0.00005 mm (0.000002 in) with display increments of 0.001 mm for fine, repeatable readings.
• Flatness: 0.000012 mm (0.3 μm) flatness ensures consistent contact and stable measurements across surfaces.
• Protection: IP65 rated enclosure protects against dust ingress and water jets in shop and outdoor environments.
• Measuring faces: Carbide‑tipped measuring faces provide exceptional wear resistance for longer tool life.
• Data output options: Cable data output 900-05-4/5 for wired transfers and optional wireless data output 901-00-4 for wireless logging.
• Display behavior: Upon switch‑on, the display shows the actual absolute measuring position for fast setup.
• Power management: Automatic shut‑off helps maximize battery life between uses.
• Measuring modes: Absolute or incremental measuring modes to suit setup, part inspection, or repetitive measurements.
• Construction: Grey painted steel frame combines rigidity with a comfortable, durable grip for daily use.
• Standard accessories: Battery, Ball Anvil, Calibration Certificate, Warranty Card, and Instruction Manual included.
• Range note: Standard version supports broad range requirements for diverse measurement tasks.

This digital outside micrometer excels in precise diameter checks on shafts, housings, and cylindrical components where durability and quick data capture matter. The carbide faces resist wear in busy production lines, while the IP65 protection keeps readings reliable in dusty or damp environments. Choose wired or wireless data outputs to integrate measurements with your SPC systems or handheld devices, and switch between absolute and incremental modes to fit both new part setup and ongoing quality checks. Ideal for machine shops, automotive assemblies, maintenance services, and field engineering where accurate, repeatable external measurements are essential.
