ITP Straight Styli - Type A - Silicon Nitride Ball - M5 Thread x 65.5mm Overall Length - TKM5S10011065
| Styli Type | Type A |
| Thread Size | M5 |
| Ball Diameter (DK) | 10 |
| Overall Length (L) | 65.5 |
Learn more about Klarna
Description
The ITP Straight Styli Type A with a silicon nitride ball is a precision probing stylus designed for everyday measurement tasks in CMM and scanning workflows. It’s crafted for technicians who need reliable contact and repeatable results, especially when working with aluminum workpieces.
- Thread: M5 male thread for secure mounting in standard probe assemblies.
- Overall length: 65.5 mm for consistent reach in tight or cluttered setups.
- Ball material: Silicon nitride ceramic ball, known for hardness and low wear during repeated probing.
- Stem material: High-performance ceramic stem that is light and rigid, reducing tip deflection.
- Stylus style: Straight, Type A geometry optimized for everyday standard use.
- Ideal use: Particularly effective for scanning untreated aluminum workpieces to maintain measurement accuracy.
- Size options: Ball sizes range from Ø5.0 mm to Ø10.0 mm; custom sizes available on request.
Thanks to its lightweight ceramic construction and durable silicon nitride ball, this stylus delivers smooth, responsive contact and stable data capture across routine inspections. The combination of a rigid ceramic stem and a precisely engineered ball minimizes deflection, helping you achieve consistent measurements even in challenging setups. With a versatile 65.5 mm length and M5 thread, it integrates easily into a wide range of probing heads and fixtures. If your application requires a different ball size, Ø5.0–Ø10.0 mm variants can be requested via the configurator or by email to match your specific material and tolerance needs.
Part Numbers
- Protool Part Number
- ITP-TKM5S10011065
- Brand
- ITP
- Category
- Styli
