Widin Carbide End Mill - 4 Flute Tapered Neck For Finishing Mold & Die - 2mm x 2.5

Widin Carbide End Mill - 4 Flute Tapered Neck For Finishing Mold & Die (DB734)


From
£35.39
View Products
Need Help?
Contact Sales

This high-performance end mill is specifically designed for precision finishing applications in mold and die machining. With its 4 flutes and tapered neck design, it offers excellent cutting performance and optimal chip evacuation. The tapered neck provides enhanced stability and reduces deflection, ensuring precise and accurate cuts. Engineered to machine high hardened materials up to HRc70, this end mill can tackle even the toughest materials with ease. Its newly developed raw material and advanced ALTiN+HH coating contribute to its exceptional performance, making it suitable for dry cutting and high-speed cutting operations.


Product SKU Cutter Diameter Number of Flutes Flute Length Overall Length Shank Diameter Reach Radius Taper Angle Price Stock
ESB734020-2.5 2 4 2 60 4 25 1 2.5° £35.39 0
ESB734020-3.5 2 4 2 60 4 18 1 3.5° £35.39 0
ESB734025-2.5 2.5 4 3 60 4 20 1.25 2.5° £35.39 0
ESB734025-3.0 2.5 4 3 60 4 17 1.25 £35.39 0
ESB734030-2.0 3 4 3 70 6 46 1.5 £44.00 0
ESB734030-2.5 3 4 3 70 6 37 1.5 2.5° £44.00 0
ESB734040-2.0 4 4 4 70 6 33 2 £44.00 0
ESB734040-2.5 4 4 4 70 6 27 2 2.5° £44.00 0
ESB734050-2.5 5 4 5 70 6 16 2.5 2.5° £44.00 0
ESB734060-1.5 6 4 6 100 8 44 3 1.5° £52.61 0
ESB734060-2.5 6 4 6 100 8 29 3 2.5° £52.61 1
ESB734080-1.5 8 4 8 100 10 46 4 1.5° £73.18 0
ESB734080-2.5 8 4 8 100 10 31 4 2.5° £73.18 0
ESB734100-1.5 10 4 10 110 12 48 5 1.5° £95.18 0
ESB734100-2.5 10 4 10 110 12 33 5 2.5° £95.18 0
