Widin | Authorised UK Distributor
Widin Live Centre

Full Tipped Dead Centre - LM-AN Type

  • FULL TIPPED DEAD CENTER
  • Morse Tapers Available - No. 1 - No. 7
  • Run Out 0.00012" / 0.0002" or 0.003mm /0.005mm

  • Starting from
    £96.36
    inc. VAT
    In this range
    7
    products
    In stock now
    0
    ready to dispatch
    Browse all 7 products

    Click any SKU to view full product details, specifications and datasheets.

    Product SKU Size Head Diameter Point Length Concentricity GL L2 L3 L4 L N Price Stock Order
    LM-1AN MT1 12.2 31.5 0.003 12.065 5 36.5 53.5 90 M16 £96.36 5 days
    LM-2AN MT2 18 41.5 0.003 17.78 6.5 48 64 112 M22 £126.99 5 days
    LM-3AN MT3 24 49.5 0.003 23.825 7.5 57 81 138 M27 £133.59 5 days
    LM-4AN MT4 31.6 62.5 0.003 31.267 10 72.5 102.5 175 M36 £153.27 5 days
    LM-5AN MT5 44.7 77 0.003 44.399 11 88 129.5 217.5 M48 £175.20 5 days
    LM-6AN MT6 63.8 96.5 0.005 63.348 11.5 108 182 290 M68 £492.34 5 days
    LM-7AN MT7 83.6 108.5 0.005 83.058 11.5 120 250 370 M90 £432.01 5 days
