Palbit Arbor Mounting Holder - For XD10T3 Inserts - 52mm Cutter Diameter - 181027700
| Insert Size & Shape | XD10T3 |
| Depth of Cut Maximum (APMX) | 1 |
| Cutting Item Count (CICT) | 5 |
| Connection Diameter (DCONMS) | 22 |
| Adaptive Interface Machine Direction | Arbor Mounting |
| Contact Surface Machine Side (DCSFMS) | 40 |
Learn more about Klarna
Palbit Arbor Mounting Holder for XD10T3 inserts delivers secure retention and rigid support for high-precision grooving and parting in CNC turning and milling operations. Built to pair with XD10T3 inserts, it ensures consistent performance across demanding production runs.
- XD10T3 insert compatibility: Engineered to securely accommodate XD10T3 inserts for reliable tool-to-part interface.
- 52 mm cutter diameter: Designed for a 52 mm cutting diameter to optimize balance between rigidity and accessibility.
- Secure insert retention: Precision clamping and dual-contact geometry minimize insert movement during heavy cutting.
- High rigidity and stability: Sturdy arbor holder construction provides minimal deflection for improved surface finish and dimensional accuracy.
This holder helps reduce runout and chatter, delivering steady cutting performance, longer tool life, and reduced downtime in tough production environments. Ideal for grooving and parting tasks where precision and tool life are critical.
| Insert Size & Shape | XD10T3 |
| Depth of Cut Maximum (APMX) | 1 |
| Cutting Item Count (CICT) | 5 |
| Connection Diameter (DCONMS) | 22 |
| Adaptive Interface Machine Direction | Arbor Mounting |
| Contact Surface Machine Side (DCSFMS) | 40 |
| Tool Cutting Edge Angle (KAPR) | 95 |
| Cutting Diameter (DC) | 52 |
| Torque (TQ) | 3 |
| Functional Length (LF) | 50 |
| Axial Rake Angel (GAMP) | 7 |
| Rdial Rake Angle (GAMF) | -2 |
