Vortex Carbide Corner Rounding Cutter TiAlN Coated - 3mm x R0.1 (VOR45-CCRC-0.10)
| Radius | 0.1 |
| Centre Dia | 0.5 |
| Neck Diameter | 0.8 |
| Flute Length | 5 |
| Shank Diameter | 4 |
| Overall Length | 50 |
Learn more about Klarna
The VOR45-CCRC-0.10 solid carbide corner rounding cutter from Vortex is built for precision external radii on a wide range of materials, making it ideal for machinists and fabricators tackling small, detailed features.
- Diameter and radius: 3 mm cutting diameter with a 0.10 mm external corner radius for tight, consistent curves.
- Flute configuration: 2/4 flute geometry delivers a balanced combination of material removal and surface finish.
- Material: Solid carbide for high stiffness, wear resistance, and long tool life.
- Coating: TiAlN coating enhances hardness and heat resistance, boosting performance on a range of metals.
- Applications: Specifically designed to machine external radii on all materials, with strong capability on steel, stainless steel, cast iron, copper, and aluminum.
- Brand and series: Part of the Vortex VOR45-CCRC family of corner rounding cutters crafted for reliable radius control.
With this cutter, you can produce precise, repeatable radii on enclosures, brackets, housings, and other components, reducing secondary deburring and finishing time. The TiAlN coating helps maintain a sharp edge under heat, enabling higher feed rates and longer tool life across ferrous and non-ferrous materials. The 3 mm diameter and 0.10 mm radius are ideal for compact features and tight corners, delivering a smooth, professional finish on parts made from steel, stainless steel, cast iron, copper, and aluminum.
| Radius | 0.1 |
| Centre Dia | 0.5 |
| Neck Diameter | 0.8 |
| Flute Length | 5 |
| Shank Diameter | 4 |
| Overall Length | 50 |
What time are Protool open?
We are open Monday to Friday between 8:30am and 5pm.
Do you offer Free Next Day delivery?
Yes! We offer Free Next Day delivery via Royal Mail Tracked 24 on all orders over £50 ex VAT*. We also offer Free DPD Local Next Day delivery on all orders over £100 ex VAT*.
We also offer the following:
- Royal Mail Tracked 24 — £5.90 (FREE on orders over £50 ex VAT*). Order before 4:30pm for next day delivery. No signature required.
- DPD Local Next Day — £8.00 (FREE on orders over £100 ex VAT*). Standard next day delivery to UK mainland addresses.
- Royal Mail Special Delivery — £12.50. Guaranteed delivery before 1pm the next working day.
- DPD Saturday Delivery — £25.00. Must be ordered on Friday before 4pm. Pre-12pm delivery.
For delivery to Scottish Highlands & Islands, Northern Ireland, Republic of Ireland, or overseas locations, additional charges apply. Please see our delivery page for full details, or call us on 01732 887 334.
*T's & C's and exclusions apply. Please see our delivery page for more information on all our services.
Full Range: Vortex Carbide Corner Rounding Cutter TiAlN Coated (VOR45-CCRC)
View full collection →You are viewing PRO1500379. Click any other SKU to view its full details.
| Product SKU | Radius | Centre Dia | Neck Diameter | Flute Length | Shank Diameter | Overall Length | Price | Stock | Order |
|---|---|---|---|---|---|---|---|---|---|
| PRO1500379 Viewing | 0.1 | 0.5 | 0.8 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500380 | 0.15 | 0.5 | 0.9 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500381 | 0.2 | 0.5 | 1 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500382 | 0.25 | 0.5 | 1.1 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500383 | 0.3 | 0.5 | 1.2 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500384 | 0.4 | 0.5 | 1.4 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500385 | 0.5 | 1.5 | 2.7 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500386 | 0.6 | 1.5 | 2.7 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500387 | 0.7 | 1.5 | 3.2 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500388 | 0.75 | 1.5 | 3.2 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500389 | 0.8 | 1.5 | 3.7 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500390 | 0.9 | 1.5 | 3.7 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500391 | 1 | 1.5 | 3.7 | 5 | 4 | 50 | £9.52 | In Stock | |
| PRO1500392 | 1.25 | 1.5 | 4.2 | 5 | 6 | 50 | £10.04 | In Stock | |
| PRO1500393 | 1.5 | 1.5 | 4.7 | 5 | 6 | 50 | £16.96 | In Stock | |
| PRO1500394 | 1.75 | 1.5 | 5.2 | 5 | 6 | 50 | £17.31 | In Stock | |
| PRO1500395 | 2 | 1.5 | 5.7 | 5 | 6 | 50 | £17.31 | In Stock | |
| PRO1500396 | 2.25 | 1.5 | 6.2 | 10 | 8 | 60 | £29.42 | In Stock | |
| PRO1500397 | 2.5 | 1.5 | 6.7 | 10 | 8 | 60 | £29.42 | In Stock | |
| PRO1500398 | 3 | 1.5 | 7.7 | 10 | 8 | 60 | £29.42 | 4-6 weeks | |
| PRO1500399 | 4 | 2 | 10.2 | 15 | 12 | 75 | £48.98 | In Stock | |
| PRO1500400 | 5 | 3 | 13.2 | 15 | 14 | 75 | £69.75 | In Stock | |
| PRO1500401 | 6 | 3 | 15.2 | 20 | 16 | 75 | £123.40 | In Stock |
