Vortex Carbide Corner Rounding Cutter TiAlN Coated - 3mm x R0.8 (VOR45-CCRC-0.80)
| Radius | 0.8 |
| Centre Dia | 1.5 |
| Neck Diameter | 3.7 |
| Flute Length | 5 |
| Shank Diameter | 4 |
| Overall Length | 50 |
Learn more about Klarna
The Vortex VOR45-CCRC-0.80 carbide corner rounding cutter is a precision tool designed for machinists and fabricators who need clean, repeatable external radii on a variety of materials. With a 3 mm diameter and a 0.8 mm corner radius, it delivers reliable edge rounding in a single, efficient pass.
- Solid Carbide Construction: rigid, wear‑resistant geometry built for long tool life and consistent performance.
- TiAlN Coating: high‑temperature wear resistance that helps maintain sharpness and enables faster cutting speeds.
- External Radius Corner Rounding: precise corner rounding for smooth edges and reliable part fit in assemblies.
- Radius Range: part of the VOR45‑CCRC family that covers radii from R0.1 to R6.0 mm, with this model delivering R0.8 mm.
- Flute Configuration: available in 2‑ and 4‑flute designs to balance surface finish, chip evacuation, and cutting efficiency.
- Material Compatibility: excels on Steel, Stainless Steel, Cast Iron, Copper and Aluminium for versatile metalworking applications.
This cutter simplifies finishing tasks by providing crisp, repeatable radii across a broad material range, reducing post‑processing and improving part quality. The combination of solid carbide rigidity, TiAlN durability, and thoughtful flute geometry supports efficient machining, better surface finish, and longer tool life in demanding external radii operations.
| Radius | 0.8 |
| Centre Dia | 1.5 |
| Neck Diameter | 3.7 |
| Flute Length | 5 |
| Shank Diameter | 4 |
| Overall Length | 50 |
What time are Protool open?
We are open Monday to Friday between 8:30am and 5pm.
Do you offer Free Next Day delivery?
Yes! We offer Free Next Day delivery via Royal Mail Tracked 24 on all orders over £50 ex VAT*. We also offer Free DPD Local Next Day delivery on all orders over £100 ex VAT*.
We also offer the following:
- Royal Mail Tracked 24 — £5.90 (FREE on orders over £50 ex VAT*). Order before 4:30pm for next day delivery. No signature required.
- DPD Local Next Day — £8.00 (FREE on orders over £100 ex VAT*). Standard next day delivery to UK mainland addresses.
- Royal Mail Special Delivery — £12.50. Guaranteed delivery before 1pm the next working day.
- DPD Saturday Delivery — £25.00. Must be ordered on Friday before 4pm. Pre-12pm delivery.
For delivery to Scottish Highlands & Islands, Northern Ireland, Republic of Ireland, or overseas locations, additional charges apply. Please see our delivery page for full details, or call us on 01732 887 334.
*T's & C's and exclusions apply. Please see our delivery page for more information on all our services.
Full Range: Vortex Carbide Corner Rounding Cutter TiAlN Coated (VOR45-CCRC)
View full collection →You are viewing PRO1500389. Click any other SKU to view its full details.
| Product SKU | Radius | Centre Dia | Neck Diameter | Flute Length | Shank Diameter | Overall Length | Price | Stock | Order |
|---|---|---|---|---|---|---|---|---|---|
| PRO1500379 | 0.1 | 0.5 | 0.8 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500380 | 0.15 | 0.5 | 0.9 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500381 | 0.2 | 0.5 | 1 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500382 | 0.25 | 0.5 | 1.1 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500383 | 0.3 | 0.5 | 1.2 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500384 | 0.4 | 0.5 | 1.4 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500385 | 0.5 | 1.5 | 2.7 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500386 | 0.6 | 1.5 | 2.7 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500387 | 0.7 | 1.5 | 3.2 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500388 | 0.75 | 1.5 | 3.2 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500389 Viewing | 0.8 | 1.5 | 3.7 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500390 | 0.9 | 1.5 | 3.7 | 5 | 4 | 50 | £42.46 | In Stock | |
| PRO1500391 | 1 | 1.5 | 3.7 | 5 | 4 | 50 | £9.52 | In Stock | |
| PRO1500392 | 1.25 | 1.5 | 4.2 | 5 | 6 | 50 | £10.04 | In Stock | |
| PRO1500393 | 1.5 | 1.5 | 4.7 | 5 | 6 | 50 | £16.96 | In Stock | |
| PRO1500394 | 1.75 | 1.5 | 5.2 | 5 | 6 | 50 | £17.31 | In Stock | |
| PRO1500395 | 2 | 1.5 | 5.7 | 5 | 6 | 50 | £17.31 | In Stock | |
| PRO1500396 | 2.25 | 1.5 | 6.2 | 10 | 8 | 60 | £29.42 | In Stock | |
| PRO1500397 | 2.5 | 1.5 | 6.7 | 10 | 8 | 60 | £29.42 | In Stock | |
| PRO1500398 | 3 | 1.5 | 7.7 | 10 | 8 | 60 | £29.42 | 4-6 weeks | |
| PRO1500399 | 4 | 2 | 10.2 | 15 | 12 | 75 | £48.98 | In Stock | |
| PRO1500400 | 5 | 3 | 13.2 | 15 | 14 | 75 | £69.75 | In Stock | |
| PRO1500401 | 6 | 3 | 15.2 | 20 | 16 | 75 | £123.40 | In Stock |
