Asimeto Plug Thread Gauge (Go/NoGo) - Imperial - Right Hand - ASMEB1.20.1-2013 - 1/16 x 27
| Thread Form | NPT |
| Size | 1/16 |
| Pitch | 27 |
| Gauge Type | Plug Gauge (Go/NoGo) |
Learn more about Klarna
Compatible certification
The ones our customers buy most.
Description
The Asimeto Plug Thread Gauge (Go/NoGo) delivers precise internal thread verification in imperial sizes, crafted for quality control teams, machinists, and manufacturing environments. This right-hand gauge adheres to ASMEB1.20.1-2013 standards and uses a 3-step L3 design to provide thorough depth and tolerance checks in a single instrument.
- Go/NoGo with 3-step L3 design: Enables quick go/no-go assessment plus depth verification for reliable internal thread conformity.
- Right-Hand configuration: Optimized for common right-hand thread orientations encountered in machining and assembly work.
- Imperial size specification: 1/16 x 27 for precise verification of your imperial-threaded components.
- ASMEB1.20.1-2013 compliant: Ensures measurements align with the established standard for internal thread gauging.
- Compact, hand-ready tool: Designed for straightforward use in quality control stations, machining cells, and inspection benches.
Using this gauge helps you quickly confirm thread accuracy, reduce the risk of inserting defective parts, and streamline SPC documentation in production. It supports efficient inspection of threaded holes and fittings, minimizes scrap from mis-tapped components, and provides dependable, repeatable results across operators and shifts.
