Asimeto Plug Thread Gauge (Go/NoGo) - Imperial - Right Hand - ASMEB1.20.1-2013 - 1/2 x 14
| Thread Form | NPT |
| Size | 1/2 |
| Pitch | 14 |
| Gauge Type | Plug Gauge (Go/NoGo) |
| Thread Direction | Right Hand |
| Tolerance | ASMEB1.20.1-2013 |
Learn more about Klarna
Asimeto Plug Thread Gauge (Go/NoGo) in Imperial sizes provides precise internal thread verification aligned with ASMEB1.20.1-2013 standards. Designed for right-hand threads, this gauge helps machinists, quality control teams, and manufacturers quickly confirm thread conformity during inspection and setup.
- Size & Orientation: Imperial 1/2" x 14 threads per inch, right-hand thread
- Go/NoGo Gauging: Quick pass/fail assessment to verify legitimate thread engagement
- 3‑Step L3 Design: Three distinct depths ensure comprehensive checks of thread depth and tolerance
- Standards Compliance: Conforms to ASMEB1.20.1-2013 for accurate internal thread gauging
This gauge delivers reliable, repeatable results that help prevent mismatches in fastener assemblies and reduce rework. It’s ideal for quality control in machining, assembly lines, and manufacturing environments where precise internal threading matters and consistent inspection is essential.
| Thread Form | NPT |
| Size | 1/2 |
| Pitch | 14 |
| Gauge Type | Plug Gauge (Go/NoGo) |
| Thread Direction | Right Hand |
| Tolerance | ASMEB1.20.1-2013 |
| Middle Diameter Size | 0.77843 |
| Gauge Tolerance | ± 0.0002 |
What time are Protool open?
We are open Monday to Friday between 8:30am and 5pm.
Do you offer Free Next Day delivery?
Yes! We offer Free Next Day delivery via Royal Mail Tracked 24 on all orders over £50 ex VAT*. We also offer Free DPD Local Next Day delivery on all orders over £100 ex VAT*.
We also offer the following:
- Royal Mail Tracked 24 — £5.90 (FREE on orders over £50 ex VAT*). Order before 4:30pm for next day delivery. No signature required.
- DPD Local Next Day — £8.00 (FREE on orders over £100 ex VAT*). Standard next day delivery to UK mainland addresses.
- Royal Mail Special Delivery — £12.50. Guaranteed delivery before 1pm the next working day.
- DPD Saturday Delivery — £25.00. Must be ordered on Friday before 4pm. Pre-12pm delivery.
For delivery to Scottish Highlands & Islands, Northern Ireland, Republic of Ireland, or overseas locations, additional charges apply. Please see our delivery page for full details, or call us on 01732 887 334.
*T's & C's and exclusions apply. Please see our delivery page for more information on all our services.
Full Range: Asimeto Plug Thread Gauges (Go/NoGo) - Imperial - Right Hand - ASMEB1.20.1-2013
View full collection →You are viewing 690-44-1. Click any other SKU to view its full details.
| Product SKU | Size | Pitch | Middle Diameter Size | Gauge Tolerance | Price | Stock | Order |
|---|---|---|---|---|---|---|---|
| 690-40-1 | 1/16 | 27 | 0.28118 | ± 0.0002 | £74.85 | In Stock | |
| 690-41-1 | 1/8 | 27 | 0.37360 | ± 0.0002 | £79.64 | 4 weeks | |
| 690-42-1 | 1/4 | 18 | 0.49163 | ± 0.0002 | £91.44 | 4 weeks | |
| 690-43-1 | 3/8 | 18 | 0.62701 | ± 0.0002 | £101.76 | In Stock | |
| 690-44-1 Viewing | 1/2 | 14 | 0.77843 | ± 0.0002 | £114.66 | 4 weeks | |
| 690-45-1 | 3/4 | 14 | 0.98887 | ± 0.0002 | £129.78 | In Stock | |
| 690-46-1 | 1 | 11.5 | 1.23863 | ± 0.0003 | £151.54 | In Stock | |
| 690-47-1 | 1.1/4 | 11.5 | 1.58338 | ± 0.0003 | £212.37 | 4 weeks | |
| 690-48-1 | 1.1/2 | 11.5 | 1.82234 | ± 0.0003 | £240.02 | In Stock | |
| 690-49-1 | 2 | 11.5 | 2.29627 | ± 0.0003 | £256.98 | 4 weeks | |
| 690-50-1 | 2.1/2 | 8 | 2.76216 | ± 0.0004 | £272.46 | 4 weeks | |
| 690-51-1 | 3 | 8 | 3.38850 | ± 0.0004 | £301.59 | 4 weeks |
