Asimeto Ring Thread Gauge (Go/NoGo) - Imperial - Right Hand - ASMEB1.20.1-2013 - 1.1/2 x 11.5
| Thread Form | NPT |
| Size | 1.1/2 |
| Pitch | 11.5 |
| Gauge Type | Ring Gauge (Go/NoGo) |
| Thread Direction | Right Hand |
| Tolerance | ASMEB1.20.1-2013 |
Learn more about Klarna
Asimeto Ring Thread Gauges (Go/NoGo) in Imperial sizes are designed for precise external thread inspection. This right-hand gauge features a 1.1/2 x 11.5 size and a 3-step L3 design, conforming to ASMEB1.20.1-2013 standards for reliable quality control in machining and manufacturing.
- Go/NoGo validation: Quickly determine if external threads meet spec by comparing against limit conditions, reducing guesswork and scrap.
- Imperial size, right-hand: Suited for standard imperial threads with right-hand pitch, ensuring consistent testing results in common setups.
- 3-step L3 design: Three precise engagement steps provide clear pass/fail indications and accurate depth verification.
- ASMEB1.20.1-2013 compliant: Built to industry-standard tolerances, supporting compliance and documentation in quality systems.
- Durable, workshop-ready construction: Designed for daily use in machine shops and manufacturing environments with reliable performance over time.
Use this ring gauge to standardize external thread inspection across production runs, train operators for quick go/no-go checks, and capture objective evidence of conformance for QA records. The 3-step L3 design enables fast, repeatable checks, helping improve first-pass yields, reduce rework, and ensure proper fit in threaded assemblies.
| Thread Form | NPT |
| Size | 1.1/2 |
| Pitch | 11.5 |
| Gauge Type | Ring Gauge (Go/NoGo) |
| Thread Direction | Right Hand |
| Tolerance | ASMEB1.20.1-2013 |
| Middle Diameter Size | 1.82234 |
| Gauge Tolerance | ± 0.0004 |
What time are Protool open?
We are open Monday to Friday between 8:30am and 5pm.
Do you offer Free Next Day delivery?
Yes! We offer Free Next Day delivery via Royal Mail Tracked 24 on all orders over £50 ex VAT*. We also offer Free DPD Local Next Day delivery on all orders over £100 ex VAT*.
We also offer the following:
- Royal Mail Tracked 24 — £5.90 (FREE on orders over £50 ex VAT*). Order before 4:30pm for next day delivery. No signature required.
- DPD Local Next Day — £8.00 (FREE on orders over £100 ex VAT*). Standard next day delivery to UK mainland addresses.
- Royal Mail Special Delivery — £12.50. Guaranteed delivery before 1pm the next working day.
- DPD Saturday Delivery — £25.00. Must be ordered on Friday before 4pm. Pre-12pm delivery.
For delivery to Scottish Highlands & Islands, Northern Ireland, Republic of Ireland, or overseas locations, additional charges apply. Please see our delivery page for full details, or call us on 01732 887 334.
*T's & C's and exclusions apply. Please see our delivery page for more information on all our services.
Full Range: Asimeto Ring Thread Gauges (Go/NoGo) - Imperial - Right Hand - ASMEB1.20.1-2013
View full collection →You are viewing 690-48-3. Click any other SKU to view its full details.
| Product SKU | Size | Pitch | Middle Diameter Size | Gauge Tolerance | Price | Stock | Order |
|---|---|---|---|---|---|---|---|
| 690-40-3 | 1/16 | 27 | 0.28118 | ± 0.0003 | £133.83 | In Stock | |
| 690-41-3 | 1/8 | 27 | 0.37360 | ± 0.0003 | £151.43 | In Stock | |
| 690-42-3 | 1/4 | 18 | 0.49163 | ± 0.0003 | £164.34 | 4 weeks | |
| 690-43-3 | 3/8 | 18 | 0.62701 | ± 0.0003 | £216.41 | In Stock | |
| 690-44-3 | 1/2 | 14 | 0.77843 | ± 0.0003 | £260.60 | In Stock | |
| 690-45-3 | 3/4 | 14 | 0.98887 | ± 0.0003 | £294.66 | 4 weeks | |
| 690-46-3 | 1 | 11.5 | 1.23863 | ± 0.0004 | £328.68 | 4 weeks | |
| 690-47-3 | 1.1/4 | 11.5 | 1.58338 | ± 0.0004 | £459.00 | 4 weeks | |
| 690-48-3 Viewing | 1.1/2 | 11.5 | 1.82234 | ± 0.0004 | £493.43 | 4 weeks | |
| 690-49-3 | 2 | 11.5 | 2.29627 | ± 0.0004 | £520.07 | 4 weeks | |
| 690-50-3 | 2.1/2 | 8 | 2.76216 | ± 0.0005 | £542.75 | 4 weeks | |
| 690-51-3 | 3 | 8 | 3.38850 | ± 0.0005 | £570.15 | 4 weeks |
