Omega Boring Bar Steel Shank - Screw Clamp Left Hand 95 Deg - For CCMT09T3/CCGT09T3 Inserts - S20S-SCLCL09

Omega S20S-SCLCL09 is a left‑hand, 95‑degree boring bar with a solid steel shank, designed to securely hold CCMT09T3/CCGT09T3 inserts for precise turning, facing, and chamfering. Built for rigidity and reliable insert clamping, it minimizes vibration to deliver smooth, consistent cuts.

• 20 mm steel shank: Robust, rigid construction provides stable performance across heavy cutting tasks.
• Left‑hand, 95° approach: Optimized geometry for clearances and efficient chip flow in tight bores.
• Screw clamp system: Secure insert retention with a simple screw mechanism for quick, repeatable changeovers.
• Insert compatibility: Specifically tuned for CCMT09T3 and CCGT09T3 style inserts (CCMT/CCGT 09 series).
• Length and reach: 250 mm overall length with a 32 mm reach to access deeper diameters.
• Holder style: SCLCR/L interface ensures easy mounting in standard boring bar holders.
• Coolant: Through‑coolant not included, aligning with this model’s solid steel design.
• Brand: Omega, a trusted name in precision tooling.

The screw clamp design minimizes insert movement and vibration, delivering clean diameters and smooth finishes. The 95° approach angle provides solid support in demanding boring applications and helps with chip evacuation, especially on deeper bores. With a 20 mm steel shank and rigid construction, this boring bar sustains accurate cuts through both roughing and finishing passes. Its left‑hand orientation is ideal for common turning setups, enabling efficient operations from the left side of the workpiece. For best performance, clamp the insert to at least one‑third of the bar length to maximize rigidity and tool life.
