Dormer Pramet C60 5/32 Inch HSS Double Ended Flatted Shank 2 Flute Slot Drill Regular Length

Two-ended, regular-length end mill designed for shoulder milling, slot milling, and ramping in free-machining steel. The Dormer Pramet C60 5/32" HSS slot drill provides two cutting edges in one tool, delivering reliable performance in production and workshop settings.

• Diameter: 5/32" (0.15625")
• End type: Double-ended end mill with two cutting ends for extended tool life
• Flutes: 2-flute geometry for efficient material removal and a smoother finish
• Cutting length (LOC): 7/16" (0.4375")
• Overall length: 3 1/8"
• Shank: 3/8" Weldon shank (ANSI standard) for secure mounting
• Material & finish: High-Speed Steel with bright finish for durability and easy chip evacuation
• Helix angle: 30° for efficient cutting, improved chip control, and good surface finish
• Applications: Shoulder milling, slot milling, and ramping in free-machining steel
• Brand & standard: Dormer Pramet C60, ANSI standard

This end mill is built to maximize productivity in everyday steel milling tasks. With two cutting ends, you can rotate to a fresh edge without stopping for tool changes, increasing uptime for both small batches and longer production runs. The 30° helix enhances chip evacuation and helps reduce burr formation during shoulder and slot milling in soft steels. The Weldon shank ensures a secure fit in standard tool holders, minimizing runout and improving accuracy. The 7/16" depth of cut and 5/32" diameter provide a practical combination of reach and rigidity for pocketing, slotting, and ramping operations in free-machining steel (C60). This makes it a versatile choice for general-purpose milling in professional shops.
