Palbit Indexable Milling Insert - for Profile Milling - XDHW 040110 PH6910

Palbit Indexable Milling Insert - for Profile Milling - XDHW 040110 PH6910

SKU:PAL-111057354
The Palbit XDHW indexable milling insert is engineered for precision profile milling, delivering exceptional results on complex contours and detailed surfaces. Built from durable carbide and feat... Read more ↓
Material Compatibility
P
K
Specification
ISO CodeXDHW 040110 PH6910
Insert Size and ShapeXD0401
Product LineLINEPRO 41095
GradePH6910
HandNeutral
Cutting Edge Count (CEDC)2
View all specifications ↓
£7.16
Prices shown ex. VAT
5 days estimated lead time — subject to availability
View Other Sizes →
Suitable Holders
Free delivery over £50 ex VAT
Secure checkout
14-day returns
30+ years expertise
Klarna
Pay in 3 interest-free instalments. No extra cost if paid on time. 18+ only.
Learn more about Klarna
Speak to our team
01732 887334
Mon – Thurs 8:30 – 17:30 · Fri 8:30 – 16:30

The Palbit XDHW indexable milling insert is engineered for precision profile milling, delivering exceptional results on complex contours and detailed surfaces. Built from durable carbide and featuring an advanced cutting geometry, this insert is designed to provide smooth machining, superior surface finishes, and extended tool life.

  • Geometric Code: XDHW geometry optimized for profile milling.
  • Material: Durable carbide construction for demanding milling applications.
  • Application: Specifically suited for precision profile milling of complex contours and detailed surfaces.
  • Cutting Performance: Advanced cutting geometry enables smooth machining and efficient chip handling.
  • Finish & Tool Life: Produces superior surface finishes while extending insert life.
  • Indexable Design: Replaceable insert edge reduces downtime and maintains consistent performance.
  • Model Code: 040110 PH6910 within the Palbit XDHW family for clear identification.

Designed to meet the needs of precision shops, this Palbit XDHW insert delivers reliable, repeatable results on intricate profiles, helping you achieve clean cuts and high-quality surfaces with fewer tool changes.

ISO Code XDHW 040110 PH6910
Insert Size and Shape XD0401
Product Line LINEPRO 41095
Grade PH6910
Hand Neutral
Cutting Edge Count (CEDC) 2
Operation Type (CTPT) Profile Milling
Tolerance Class Insert (TCINS) H
Insert Shape Code (SC) X
Inscribed Circle Diameter (IC) 4
Insert Thickness (S) 1.59
Corner Radius (RE) 1
Cutting Edge Effective Length (LE) 4
Fixing Hole Diameter (D1) 2

What time are Protool open?

We are open Monday to Friday between 8:30am and 5pm.

Do you offer Free Next Day delivery?

Yes! We offer Free Next Day delivery via Royal Mail Tracked 24 on all orders over £50 ex VAT*. We also offer Free DPD Local Next Day delivery on all orders over £100 ex VAT*.

We also offer the following:

  • Royal Mail Tracked 24 — £5.90 (FREE on orders over £50 ex VAT*). Order before 4:30pm for next day delivery. No signature required.
  • DPD Local Next Day — £8.00 (FREE on orders over £100 ex VAT*). Standard next day delivery to UK mainland addresses.
  • Royal Mail Special Delivery — £12.50. Guaranteed delivery before 1pm the next working day.
  • DPD Saturday Delivery — £25.00. Must be ordered on Friday before 4pm. Pre-12pm delivery.

For delivery to Scottish Highlands & Islands, Northern Ireland, Republic of Ireland, or overseas locations, additional charges apply. Please see our delivery page for full details, or call us on 01732 887 334.

*T's & C's and exclusions apply. Please see our delivery page for more information on all our services.

★★★★★
Nice experience staff are very helpful and interested...
Staff are very helpful and interested in providing a good service making us the customer feel valued.
Bill
★★★★★
first place we look
honest about stock and prices are competitive.
Phil
★★★★★
Polite and helpful
Staff are very helpful and polite.Goods that were in stock were dispatched same day and back orders were quick in coming through .
Graham
★★★★★
Buying experience
Phone requests are handled quickly and without any fuss. The website is easy to use and straightforward to order from. It’s especially helpful that it shows real‑time availability, so we don’t need to call to confirm whether parts will arrive.
Jeremy

Full Range: Palbit XDHW Inserts

View full collection →

You are viewing PAL-111057354. Click any other SKU to view its full details.

Product SKUISO CodeInsert Size & ShapeProduct LineInsert Shape Code (SC)Insert Thickness (S)PriceStock Order
PAL-1110573M6 XDHW 040110 PH6103XD0401LINEPRO 41095X1.59£7.16 5 days
PAL-1110532M6 XDHW 060210 PH6103XD0602LINEPRO 40095X2.38£7.16 5 days
PAL-1110905P2 XDHW 040105 PHD103XD0401LINEPRO 41095X1.59£33.65 5 days
PAL-1110573P2 XDHW 040110 PHD103XD0401LINEPRO 41095X1.59£33.65 5 days
PAL-111057378 XDHW 040110 PH6125XD0401LINEPRO 41095X1.59£7.16 5 days
PAL-111057354 ViewingXDHW 040110 PH6910XD0401LINEPRO 41095X1.59£7.16 5 days
PAL-1110573M5 XDHW 040110 PH0103XD0401LINEPRO 41095X1.59£7.16 5 days
PAL-111056578 XDHW 10T310 PH6125XD10T3LINEPRO 40595X3.97£8.20 5 days
PAL-111056554 XDHW 10T310 PH6910XD10T3LINEPRO 40595X3.97£8.20 5 days
PAL-111056586 XDHW 10T310 PH6135XD10T3LINEPRO 40595X3.97£8.20 5 days
PAL-1110565M6 XDHW 10T310 PH6103XD10T3LINEPRO 40595X3.97£8.20 In Stock
PAL-1110532P2 XDHW 060210 PHD103XD0602LINEPRO 40095X2.38£36.47 5 days
PAL-111053278 XDHW 060210 PH6125XD0602LINEPRO 40095X2.38£7.16 5 days
PAL-111053254 XDHW 060210 PH6910XD0602LINEPRO 40095X2.38£7.16 5 days
PAL-111053286 XDHW 060210 PH6135XD0602LINEPRO 40095X2.38£7.16 5 days
