Palbit Arbor Mounting Holder - For AN1004 Inserts - 40mm Cutter Diameter - 181075400
| Insert Size & Shape | AN1004 |
| Depth of Cut Maximum (APMX) | 9 |
| Cutting Item Count (CICT) | 5 |
| Connection Diameter (DCONMS) | 16 |
| Adaptive Interface Machine Direction | Arbor Mounting |
| Contact Surface Machine Side (DCSFMS) | 32 |
Learn more about Klarna
The Palbit Arbor Mounting Holder is a precision mounting accessory for CNC grooving and parting tasks. Designed to hold AN1004 inserts with maximum stability, it delivers rigidity and accuracy for dependable high-speed machining.
- Inserts compatibility: Specifically designed to fit AN1004 inserts, ensuring proper seating and alignment.
- 40 mm cutter diameter: Supports a 40 mm cutter diameter for stable chip load and finish.
- Rigid, stable construction: Engineered to maximize rigidity and minimize deflection during cutting.
- High-speed CNC suitability: Optimized for fast, clean cuts with reduced tool wear.
- Precise alignment: Provides repeatable seating and alignment for tight-tolerance applications.
- Easy installation: Simple mounting with secure clamping to prevent movement during operation.
With this holder, engineers and machinists gain reliable performance in tight-tolerance parts, delivering clean grooves and parting passes while extending insert life through improved stability and reduced vibration in demanding CNC environments.
| Insert Size & Shape | AN1004 |
| Depth of Cut Maximum (APMX) | 9 |
| Cutting Item Count (CICT) | 5 |
| Connection Diameter (DCONMS) | 16 |
| Adaptive Interface Machine Direction | Arbor Mounting |
| Contact Surface Machine Side (DCSFMS) | 32 |
| Tool Cutting Edge Angle (KAPR) | 90 |
| Cutting Diameter (DC) | 40 |
| Torque (TQ) | 1.4 |
| Functional Length (LF) | 40 |
| Axial Rake Angel (GAMP) | -7 |
| Rdial Rake Angle (GAMF) | -21 |
What time are Protool open?
We are open Monday to Friday between 8:30am and 5pm.
Do you offer Free Next Day delivery?
Yes! We offer Free Next Day delivery via Royal Mail Tracked 24 on all orders over £50 ex VAT*. We also offer Free DPD Local Next Day delivery on all orders over £100 ex VAT*.
We also offer the following:
- Royal Mail Tracked 24 — £5.90 (FREE on orders over £50 ex VAT*). Order before 4:30pm for next day delivery. No signature required.
- DPD Local Next Day — £8.00 (FREE on orders over £100 ex VAT*). Standard next day delivery to UK mainland addresses.
- Royal Mail Special Delivery — £12.50. Guaranteed delivery before 1pm the next working day.
- DPD Saturday Delivery — £25.00. Must be ordered on Friday before 4pm. Pre-12pm delivery.
For delivery to Scottish Highlands & Islands, Northern Ireland, Republic of Ireland, or overseas locations, additional charges apply. Please see our delivery page for full details, or call us on 01732 887 334.
*T's & C's and exclusions apply. Please see our delivery page for more information on all our services.
Full Range: PLUS 17190 - Arbor Mounting
View full collection →You are viewing PAL-181075400. Click any other SKU to view its full details.
| Product SKU | Insert Size and Shape | Application | Adaptive Machine Direction | Cutting Diameter (DC) | Functional Length (LF) | Price | Stock | Order |
|---|---|---|---|---|---|---|---|---|
| PAL-181076000 | AN1004 | Shouldering Cutters | Arbor Mounting | 80 | 50 | £337.57 | 5 days | |
| PAL-181075900 | AN1004 | Shouldering Cutters | Arbor Mounting | 80 | 50 | £321.70 | 5 days | |
| PAL-181075800 | AN1004 | Shouldering Cutters | Arbor Mounting | 63 | 40 | £308.77 | 5 days | |
| PAL-181075700 | AN1004 | Shouldering Cutters | Arbor Mounting | 63 | 40 | £277.77 | 5 days | |
| PAL-181075600 | AN1004 | Shouldering Cutters | Arbor Mounting | 50 | 40 | £273.33 | 5 days | |
| PAL-181075500 | AN1004 | Shouldering Cutters | Arbor Mounting | 50 | 40 | £242.15 | 5 days | |
| PAL-181075400 Viewing | AN1004 | Shouldering Cutters | Arbor Mounting | 40 | 40 | £231.62 | 5 days | |
| PAL-181075300 | AN1004 | Shouldering Cutters | Arbor Mounting | 40 | 40 | £215.93 | 5 days | |
| PAL-181076200 | AN1004 | Shouldering Cutters | Arbor Mounting | 100 | 50 | £394.58 | 5 days | |
| PAL-181076100 | AN1004 | Shouldering Cutters | Arbor Mounting | 100 | 50 | £360.44 | 5 days |
