Palbit Threaded Coupling Holder - For AN1206 Inserts - 25mm Cutter Diameter - 181117100
| Insert Size & Shape | AN1206 |
| Depth of Cut Maximum (APMX) | 11 |
| Cutting Item Count (CICT) | 2 |
| Adaptive Interface Machine Direction | Threaded Coupling |
| Contact Surface Machine Side (DCSFMS) | 21 |
| Tool Cutting Edge Angle (KAPR) | 90 |
Learn more about Klarna
Palbit Threaded Coupling Holder for AN1206 inserts is engineered for precision internal threading, delivering secure insert retention and exceptional rigidity to produce repeatable, high-quality thread forms.
- Compatibility with AN1206 inserts: Designed to mate exclusively with AN1206 inserts for reliable seating and alignment.
- Threaded coupling design: Robust interface provides secure retention and quick, repeatable setup.
- 25 mm cutter diameter: Optimized for a 25 mm cutter diameter, delivering consistent engagement and control.
- Exceptional rigidity: Rigid construction minimizes deflection under cutting loads to maintain accurate thread profiles.
- Improved chip evacuation: Geometric features promote efficient chip flow away from the cutting zone, reducing heat and buildup.
- Durable, dependable performance: Built to withstand demanding CNC environments, ensuring reliable performance across high-precision threading tasks.
With secure insert retention, precise threading, and optimized chip handling, this holder supports longer tool life and cleaner cuts in challenging CNC threading operations. Engineers and machinists rely on Palbit's precision holders for consistent results and reliable performance in high-precision applications.
| Insert Size & Shape | AN1206 |
| Depth of Cut Maximum (APMX) | 11 |
| Cutting Item Count (CICT) | 2 |
| Adaptive Interface Machine Direction | Threaded Coupling |
| Contact Surface Machine Side (DCSFMS) | 21 |
| Tool Cutting Edge Angle (KAPR) | 90 |
| Cutting Diameter (DC) | 25 |
| Torque (TQ) | 2 |
| Functional Length (LF) | 35 |
| Axial Rake Angel (GAMP) | -6 |
| Rdial Rake Angle (GAMF) | -21 |
What time are Protool open?
We are open Monday to Friday between 8:30am and 5pm.
Do you offer Free Next Day delivery?
Yes! We offer Free Next Day delivery via Royal Mail Tracked 24 on all orders over £50 ex VAT*. We also offer Free DPD Local Next Day delivery on all orders over £100 ex VAT*.
We also offer the following:
- Royal Mail Tracked 24 — £5.90 (FREE on orders over £50 ex VAT*). Order before 4:30pm for next day delivery. No signature required.
- DPD Local Next Day — £8.00 (FREE on orders over £100 ex VAT*). Standard next day delivery to UK mainland addresses.
- Royal Mail Special Delivery — £12.50. Guaranteed delivery before 1pm the next working day.
- DPD Saturday Delivery — £25.00. Must be ordered on Friday before 4pm. Pre-12pm delivery.
For delivery to Scottish Highlands & Islands, Northern Ireland, Republic of Ireland, or overseas locations, additional charges apply. Please see our delivery page for full details, or call us on 01732 887 334.
*T's & C's and exclusions apply. Please see our delivery page for more information on all our services.
Full Range: PLUS 17590 - Threaded Coupling
View full collection →You are viewing PAL-181117100. Click any other SKU to view its full details.
| Product SKU | Insert Size and Shape | Application | Adaptive Machine Direction | Cutting Diameter (DC) | Functional Length (LF) | Price | Stock | Order |
|---|---|---|---|---|---|---|---|---|
| PAL-181117200 | AN1206 | Shouldering Cutters | Threaded Coupling | 32 | 43 | £167.40 | 5 days | |
| PAL-181117100 Viewing | AN1206 | Shouldering Cutters | Threaded Coupling | 25 | 35 | £155.21 | 5 days |
