Dormer Pramet C353 11.0mm HSS-E-Powder Metal Alcrona Primax Flatted Shank 3 Flute Short Series Slot Drill DIN 327 D

Durable, precise, and ready for demanding production work, the Dormer Pramet C353 11.0 mm HSS‑E‑PM Alcrona Primax slot drill is designed for high‑reliability slotting, shoulder milling and ramping in steel and alloyed metals. This extra‑short, 3‑flute tool delivers rigidity and clean slots in tight workpieces.

• Diameter: 11.0 mm
• Number of flutes: 3
• Series: Extra‑short slot drill
• Length of cut: 13 mm
• Overall length: 70 mm
• Shank: Weldon, 12 mm
• Coating: Alcrona Primax
• Material: HSS‑E (powder metallurgy)
• Standard: DIN 327 D
• Helix angle: 30°
• Rake angle: 12°
• Applications: Shoulder milling, slot milling and ramping

This tool is engineered to handle slotting in a range of materials, including steel, cast iron, copper and their alloys, as well as titanium and its alloys. The Alcrona Primax coating minimizes built‑up edge and enhances wear resistance, while the powder‑metallurgical HSS substrate provides a tough, reliable cutting edge. The combination of a 30° helix and a 12° rake angle supports smooth chip formation and productive cutting in shallow slots, pockets, and shoulder geometry with reduced cutting forces. The Weldon 12 mm shank ensures solid clamping and minimal runout with standard toolholding, giving you consistent results across multiple setups.
