Dormer Pramet C353 7.5mm HSS-E-Powder Metal Alcrona Primax Flatted Shank 3 Flute Short Series Slot Drill DIN 327 D

The Dormer Pramet C353 7.5mm HSS-E powder-metallurgical slot drill with Alcrona Primax coating is built for precise shoulder, slot milling, and ramping in a range of metals. Its extra-short design and rugged construction make it a reliable choice for tight pockets and demanding milling tasks.

• Diameter: 7.5 mm
• Length of Cut: 10 mm
• Overall Length: 60 mm
• Shank: Weldon 10 mm
• Coating / Material: HSS-E powder-metallurgical core with Alcrona Primax coating
• Flutes: 3-flute geometry
• Helix / Rake: 30° helix, 12° rake for efficient, controlled cutting
• DIN Standard: DIN 327 D
• Shank Type: Flatted shank for secure seating and torque transfer
• Applications: Shoulder milling, slot milling, and ramping
• Material Compatibility: Suitable for steel, cast steel, cast iron, copper and copper alloys, and titanium or titanium alloys

Engineered for reliability in confined spaces, the C353 minimizes tool deflection while delivering clean slots and accurate shoulders. The Alcrona Primax coating pairs with a powder-metallurgical HSS-E core to resist wear under high-cutting forces, helping extend tool life and maintain edge stability across repeated passes. The 3-flute design provides a solid balance between rigidity and chip evacuation, making it well-suited for slotting and ramping in a variety of metallic workpieces, including titanium and copper alloys. Ideal for workshops prioritizing consistency, repeatability, and efficient material removal in compact milling operations.
