Carmex Tiny Tool Holder - Round Shank Holder For Swiss Machines to hold Carbide Small Boring Tool - 22mm Shank x 5mm Bore
Learn more about Klarna
The Carmex Tiny Tool Holder is an external turning holder designed for Swiss-type CNC lathes to hold carbide small boring tools. It’s built for back operations and uses the Tiny Tools system to deliver reliable performance with a 22 mm round shank and a 5 mm bore.
- 22 mm round shank: Round shank size designed for secure mounting on compatible holders.
- 5 mm bore: Precisely sized bore to accept carbide small boring tools.
- External turning holder: Part of the Tiny Tools family, optimized for external turning on Swiss-type machines.
- Back operations on Swiss lathes: Specially designed for back operations with a sliding head on Swiss-type CNC lathes.
- Dual-direction gripping: Tiny bar can be gripped in two directions, enabling turning on both X and Y axes.
- Internal coolant to cutting edge: Integrated coolant delivery directs fluid to the cutting edge for improved cooling and chip control.
- Coated for abrasion resistance: Coatings enhance wear resistance for longer tool life.
- Bar compatibility: Compatible with bars 3.0 mm to 10.0 mm in diameter.
The holder delivers precise, reliable performance for micro turning tasks by enabling versatile tool orientation, efficient cooling, and durable construction that suits carbide small boring tools across a wide range of bar sizes.
| Inside Diameter | 5 |
| Outside Diameter | 22 |
| d | 16 |
| L | 40 |
| L1 | 18 |
| L2 | 25 |
| dp | 4/6 |
| Key | K16 |
| Clamping Screw | S24M |
What time are Protool open?
We are open Monday to Friday between 8:30am and 5pm.
Do you offer Free Next Day delivery?
Yes! We offer Free Next Day delivery via Royal Mail Tracked 24 on all orders over £50 ex VAT*. We also offer Free DPD Local Next Day delivery on all orders over £100 ex VAT*.
We also offer the following:
- Royal Mail Tracked 24 — £5.90 (FREE on orders over £50 ex VAT*). Order before 4:30pm for next day delivery. No signature required.
- DPD Local Next Day — £8.00 (FREE on orders over £100 ex VAT*). Standard next day delivery to UK mainland addresses.
- Royal Mail Special Delivery — £12.50. Guaranteed delivery before 1pm the next working day.
- DPD Saturday Delivery — £25.00. Must be ordered on Friday before 4pm. Pre-12pm delivery.
For delivery to Scottish Highlands & Islands, Northern Ireland, Republic of Ireland, or overseas locations, additional charges apply. Please see our delivery page for full details, or call us on 01732 887 334.
*T's & C's and exclusions apply. Please see our delivery page for more information on all our services.
Full Range: Carmex Tiny Tool Holder - Round Shank Holder For Swiss Machines to hold Carbide Small Boring Tool
View full collection →You are viewing SIM22SH5. Click any other SKU to view its full details.
| Product SKU | Inside Diameter | Outside Diameter | d | L | L1 | Price | Stock | Order |
|---|---|---|---|---|---|---|---|---|
| SIM22SH3 | 3 | 22 | 16 | 40 | 18 | £96.54 | 5 days | |
| SIM22SH3-L | 3 | 22 | 16 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH4 | 4 | 22 | 16 | 40 | 18 | £96.54 | 5 days | |
| SIM22SH4-L | 4 | 22 | 16 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH5 Viewing | 5 | 22 | 16 | 40 | 18 | £96.54 | 5 days | |
| SIM22SH5-L | 5 | 22 | 16 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH6 | 6 | 22 | 16 | 40 | 18 | £96.54 | 5 days | |
| SIM22SH6-L | 6 | 22 | 16 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH8 | 8 | 22 | 20 | 40 | 18 | £96.54 | In Stock | |
| SIM22SH8-L | 8 | 22 | 20 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH10 | 10 | 22 | 20 | 40 | 18 | £96.54 | In Stock |
