Carmex Tiny Tool Holder - Round Shank Holder For Swiss Machines to hold Carbide Small Boring Tool - 22mm Shank x 10mm Bore
Learn more about Klarna
The Carmex Tiny Tool Holder is a compact external turning holder from the Tiny Tools family, designed for back operations on Swiss-type CNC lathes with a sliding head. It grips carbide small boring tools with a 22 mm round shank and a 10 mm bore, optimized for precision in tight spaces.
- 22 mm Round Shank x 10 mm Bore: Precisely sized to securely hold carbide small boring tools for Swiss-type applications.
- Dual-direction gripping: The Tiny bar can be clamped in two directions, enabling turning operations on both X and Y axes.
- Internal coolant to cutting edge: Coolant is delivered directly to the edge to improve chip control and tool life.
- Coated for abrasion resistance: Protective coating enhances wear resistance in demanding turning tasks.
- Bar compatibility: Suitable for tool bars with diameters from 3.0 mm to 10.0 mm.
- External turning holder: Specifically designed for back operations on Swiss-type machines with a sliding head.
This holder provides reliable, space-efficient tooling for carbide small boring tools, combining dual-direction gripping, integrated coolant delivery, and durable coatings to support precise, productive back-turning operations on Swiss-type CNC lathes.
| Inside Diameter | 10 |
| Outside Diameter | 22 |
| d | 20 |
| L | 40 |
| L1 | 18 |
| L2 | 25 |
| dp | 4/6 |
| Key | K16 |
| Clamping Screw | S25M |
What time are Protool open?
We are open Monday to Friday between 8:30am and 5pm.
Do you offer Free Next Day delivery?
Yes! We offer Free Next Day delivery via Royal Mail Tracked 24 on all orders over £50 ex VAT*. We also offer Free DPD Local Next Day delivery on all orders over £100 ex VAT*.
We also offer the following:
- Royal Mail Tracked 24 — £5.90 (FREE on orders over £50 ex VAT*). Order before 4:30pm for next day delivery. No signature required.
- DPD Local Next Day — £8.00 (FREE on orders over £100 ex VAT*). Standard next day delivery to UK mainland addresses.
- Royal Mail Special Delivery — £12.50. Guaranteed delivery before 1pm the next working day.
- DPD Saturday Delivery — £25.00. Must be ordered on Friday before 4pm. Pre-12pm delivery.
For delivery to Scottish Highlands & Islands, Northern Ireland, Republic of Ireland, or overseas locations, additional charges apply. Please see our delivery page for full details, or call us on 01732 887 334.
*T's & C's and exclusions apply. Please see our delivery page for more information on all our services.
Full Range: Carmex Tiny Tool Holder - Round Shank Holder For Swiss Machines to hold Carbide Small Boring Tool
View full collection →You are viewing SIM22SH10. Click any other SKU to view its full details.
| Product SKU | Inside Diameter | Outside Diameter | d | L | L1 | Price | Stock | Order |
|---|---|---|---|---|---|---|---|---|
| SIM22SH3 | 3 | 22 | 16 | 40 | 18 | £96.54 | 5 days | |
| SIM22SH3-L | 3 | 22 | 16 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH4 | 4 | 22 | 16 | 40 | 18 | £96.54 | 5 days | |
| SIM22SH4-L | 4 | 22 | 16 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH5 | 5 | 22 | 16 | 40 | 18 | £96.54 | 5 days | |
| SIM22SH5-L | 5 | 22 | 16 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH6 | 6 | 22 | 16 | 40 | 18 | £96.54 | 5 days | |
| SIM22SH6-L | 6 | 22 | 16 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH8 | 8 | 22 | 20 | 40 | 18 | £96.54 | In Stock | |
| SIM22SH8-L | 8 | 22 | 20 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH10 Viewing | 10 | 22 | 20 | 40 | 18 | £96.54 | In Stock |
