Carmex Tiny Tool Holder - Round Shank Holder For Swiss Machines to hold Carbide Small Boring Tool - 22mm Shank x 5mm Bore
Learn more about Klarna
Compatible inserts
The ones our customers buy most.
Description
The Carmex Tiny Tool Holder is a compact, round-shank external turning holder designed for Swiss-type CNC lathes with sliding heads. It securely grips carbide small boring tools with a 22 mm shank and a 5 mm bore, enabling precise back operations.
- Shank diameter: 22 mm round shank for secure mounting on Swiss machines
- Bore size: 5 mm bore to hold carbide small boring tools
- Application: External turning holder designed for back operations on Swiss-type CNC lathes with a sliding head
- Dual-direction gripping: The Tiny bar can be gripped in two directions, enabling turning on both X and Y axes
- Coolant delivery: Internal coolant channels deliver coolant to the cutting edge
- Coating: Coated holders provide abrasion resistance and extend tool life
- Bar compatibility: Compatible with bars with diameters from 3.0 mm to 10.0 mm
In use, this holder provides stable, precise support for micro-boring tasks on Swiss machines, with efficient cooling at the cutting edge to help maintain tool integrity. The two-direction gripping capability expands flexibility for various turning approaches, while the abrasion-resistant coating helps sustain performance over time. Its compatibility with a wide range of bar diameters makes it a versatile choice for small-diameter carbide tooling in tight machining spaces.
Part Numbers
- Protool Part Number
- SIM22SH5-L
- Brand
- Carmex
- Category
- Tiny Tool Holders
Need cutting data? Call 01732 887334 or email sales@protool-ltd.co.uk.
Delivery
Free UK mainland delivery on orders over £50 ex VAT. In-stock items ordered before 4:30pm are dispatched the same working day. Full delivery information.
Returns
14-day returns on unused stock items in original packaging. Special-order and bespoke tooling is non-returnable. Read our returns policy.
Technical Support
Over 30 years of machining experience behind the counter. Call 01732 887334, Mon–Thurs 8:30–17:30, Fri 8:30–16:30.
Trade Accounts
Credit accounts, contract pricing and scheduled call-off orders available for trade customers. Apply for an account.
What time are Protool open?
We are open Monday to Friday between 8:30am and 5pm.
Do you offer Free Next Day delivery?
Yes! We offer Free Next Day delivery via Royal Mail Tracked 24 on all orders over £50 ex VAT*. We also offer Free DPD Local Next Day delivery on all orders over £100 ex VAT*.
We also offer the following:
- Royal Mail Tracked 24 — £5.90 (FREE on orders over £50 ex VAT*). Order before 4:30pm for next day delivery. No signature required.
- DPD Local Next Day — £8.00 (FREE on orders over £100 ex VAT*). Standard next day delivery to UK mainland addresses.
- Royal Mail Special Delivery — £12.50. Guaranteed delivery before 1pm the next working day.
- DPD Saturday Delivery — £25.00. Must be ordered on Friday before 4pm. Pre-12pm delivery.
For delivery to Scottish Highlands & Islands, Northern Ireland, Republic of Ireland, or overseas locations, additional charges apply. Please see our delivery page for full details, or call us on 01732 887 334.
*T's & C's and exclusions apply. Please see our delivery page for more information on all our services.
Full Range: Carmex Tiny Tool Holder - Round Shank Holder For Swiss Machines to hold Carbide Small Boring Tool
View full collection →You are viewing SIM22SH5-L. Click any other SKU to view its full details.
| Product SKU | Inside Diameter | Outside Diameter | d | L | L1 | Price | Stock | Order |
|---|---|---|---|---|---|---|---|---|
| SIM22SH3 | 3 | 22 | 16 | 40 | 18 | £96.54 | 5 days | |
| SIM22SH3-L | 3 | 22 | 16 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH4 | 4 | 22 | 16 | 40 | 18 | £96.54 | 5 days | |
| SIM22SH4-L | 4 | 22 | 16 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH5 | 5 | 22 | 16 | 40 | 18 | £96.54 | 5 days | |
| SIM22SH5-L Viewing | 5 | 22 | 16 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH6 | 6 | 22 | 16 | 40 | 18 | £96.54 | 5 days | |
| SIM22SH6-L | 6 | 22 | 16 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH8 | 8 | 22 | 20 | 40 | 18 | £96.54 | In Stock | |
| SIM22SH8-L | 8 | 22 | 20 | 50 | 28 | £111.00 | 5 days | |
| SIM22SH10 | 10 | 22 | 20 | 40 | 18 | £96.54 | In Stock |
