Y.T. Indexable Saw Milling Cutter For LNGT Inserts - 80mm Diameter 2.5 to 3mm Insert Thickness 17mm Cutting Depth 8 Teeth (SBL080-2.5-22)

The Y.T. Indexable Saw Milling Cutter is a precision 80 mm tool designed for LNGT inserts. It delivers secure insert clamping, easy replacement, and high-speed performance for efficient groove milling.

• Diameter: 80 mm
• Insert thickness compatibility: supports LNGT inserts with 2.5–3 mm thickness
• Cutting depth: 17 mm
• Teeth: 8
• Insert clamping design: safe and reliable insert clamping (Swedish-certified up to 17,200 RPM)
• Rotation speed rating: maximum 17,200 RPM
• Chip evacuation: patented design prevents chip blockages within the groove
• Insert system: indexable carbide inserts for easy replacement; compatible with over 10 insert types
• Series thickness range: standard thicknesses from 1.4 mm to 5.5 mm
• Series diameter range: cutter diameter spans 50 mm to 300 mm across the entire series

With its indexable carbide inserts, you can quickly swap worn edges to maintain peak cutting performance. The robust clamping and high RPM capability support fast, accurate grooves in LNGT materials, while the patented chip evacuation design minimizes chip buildup, reducing heat and enabling cleaner finishes—even in deep cuts with 17 mm DOC. The tool’s compatibility with a broad range of insert types gives flexible material handling and extended tool life across diverse milling tasks.
