VCOIL Plug Gauge (D/E) - UNC (STI) - Heli Coil Gauge - Right Hand - 2B - 1.1/8 x 7
| Thread Form | UNC (STI) |
| Size | 1.1/8 |
| Pitch | 7 |
| Gauge Type | Plug Gauge (D/E) |
Learn more about Klarna
Compatible certification
The ones our customers buy most.
Description
The VCOIL Plug Gauge (D/E) UNC (STI) – Heli Coil Gauge is a precision go/no-go thread gauge engineered to verify Helicoil inserts and UNC threads in right-hand, 2B applications in full alignment with ANSI/ASME standards.
- Thread system: UNC (STI) thread system specified for consistent gauging of Helicoil and mating threads per ANSI/ASME guidelines.
- Go/No-Go design: Combined go and no-go ends; the go end threads into the cut by hand with controlled force, while the no-go end should not thread in more than two turns.
- Scrap marking: Scrap side is clearly identified with a red ring to quickly indicate non-conformance during inspection.
- Right-hand orientation: Right-hand gauge configuration suitable for standard machining and inspection workflows.
- Size and class: Size 1-1/8 x 7 UNC, D/E designation, 2B tolerance for precise thread validation.
- Reference temperature: Measurements referenced at 20°C to ensure consistency with standard testing conditions.
Using this gauge ensures every Helicoil insert and corresponding thread meet the required engagement and profile. The go end confirms a proper hand-start, while the no-go end prevents over-insertion, reducing scrap and rework. The red-ring scrap indicator supports rapid visual checks on the shop floor, promoting faster quality control and repeatable results across batches. The 20°C reference temperature aligns your measurements with standardized practices, facilitating reliable benchmarking over time.
