Y.T. Indexable Disc Milling Cutter For CNGX Inserts - 160mm Diameter 16mm Insert Thickness 46.5mm Cutting Depth 12 Teeth (CEL-160-16-32)

Y.T. Indexable Disc Milling Cutter for CNGX inserts is a precision milling tool designed for high-accuracy disc cutting with replaceable carbide inserts. Built for professional workshops, it combines a robust insert-clamping design with a versatile insert ecosystem to keep production moving.

• Diameter: 160 mm
• Insert Thickness: 16 mm
• Cutting Depth: 46.5 mm
• Teeth: 12
• Insert System: Indexable carbide inserts for easy replacement, compatible with over 10 insert types
• Clamping Design: Safe and reliable insert clamping for secure cutting
• Chip Evacuation: Patented chip evacuation design prevents blockages in the groove
• Speed Certification: Functionally secure up to 17,200 RPM (certified by Swedish customers)
• Series Insert Range: Standard insert thicknesses from 1.4 mm to 5.5 mm; cutter diameters from 50 mm to 300 mm across the series

This cutter minimizes downtime with easily replaceable inserts and a durable clamping system, enabling consistent, repeatable cuts in CNGX applications. The optimized chip evacuation reduces heat and buildup in deep grooves, supporting stable performance under demanding milling tasks. With compatibility across multiple insert types, it adapts to existing tooling inventories while delivering reliable, repeatable results in daily production.
