Y.T. Indexable T-Slot Cutter (3T) - Metric - 35 mm Saw Diameter for LNGT Inserts - Insert Width 5 to 5.5mm (3T1635-5.0)

The Y.T. Indexable T-Slot Cutter (model 3T1635-1.6) is a precision metric-grade milling solution tailored for T-slot machining with LNGT inserts. With a 35 mm saw diameter and a 3T indexable body, this tool provides stable engagement and rapid insert rotation, making it well-suited for maintenance work and production runs requiring consistent slot dimensions.

• Saw Diameter: 35 mm cut width offers balanced stability and effective material removal for standard T-slot geometries.
• Insert Compatibility: Accepts LNGT inserts specifically sized for widths between 5 and 5.5 mm, ensuring secure clamping and accurate profile generation.
• 3T Indexable Design: Positions three cutting edges around the perimeter, allowing operators to rotate inserts quickly to fresh edges instead of discarding used cutters.
• Tapered-Polygon Connection: Utilizes a unique tapered-polygon bore interface to lock the cutter onto the arbor, delivering repeatable center positioning and reduced vibration.
• Metric Standards: Manufactured to metric specifications, including bore and thread dimensions compatible with standard metric holders and accessories.
• Refined Cutting Geometry: Incorporates optimized rake and relief angles designed to manage chip flow efficiently and lower cutting forces during operation.

By combining a robust tapered-polygon bore with an indexable insert system, this cutter addresses common downtime issues associated with fixed-blade tools. Users can restore cutting performance by indexing inserts rather than waiting for replacements, keeping jobs moving faster. The precise center alignment minimizes radial runout, which helps preserve tight tolerances and produces cleaner slot walls with less post-machining touch-up. Additionally, optimized chip evacuation pathways prevent swarf accumulation, reducing heat stress on both the insert and the workpiece while extending overall tool service life.
